Toilet paper roll production line is used for making small toilet rolls for sale.It includes toilet paper rewinding machine,automatic band saw cutting machine and automatic multi-roll packing machine.
model:
Availability:
Quantity:
  • 1880/3000
  • YDF
  • 8441809000

f2d10

This is full automatic toilet paper roll production line.It includes toilet paper rewinding machine, automatic band saw cutter and automatic packing machine.This line can convert big tissue rolls into small toilet rolls for sale and put 6, 8, 10,12 rolls into a plastic bag.It is a better choice for toilet paper business.

lIt needs 200 square meters of space at least.

lThe packing machine is full automatic.It can load the plastic bag automatically and wrap it automatically. It has reach the international leading level.

l1~2 labor.

lIt can produce toilet rolls with core and without core.

lThe maxi width of big tissue rolls is 2100mm. So you can buy big tissue rolls with the diameter 2100 mm.

1. 1880 model Toilet Paper Rewinder Machine

171eb2

Model

1880mm ~2100mm

Applicable Raw Paper

2-3 plies 14~23g/Wood pulp paper

Finshed product

Toilet rolls with core /without core

Raw Paper Width

Max 2100mm

Raw Paper Dia

Max2100mm

Finished Size

Φ60~130 mm

Finished Core Dia

Φ35mm-Φ50mm

Raw Paper Core Dia

3(76.2 mm)

Perforation

Spiral perforating knife,Chain wheel positioning



Production Speed

200 m/min

Power

12kw

 Parameter Design

LCDTouch Screen

Control

PLC

 Paper Feeding

 3 Unwinding stands,controlled by pneumatic

 Air Pressure

0.5 Mps

Power

380V,50hz

 Optional devices

Full embossing

One set of steel to woolen embossing roller,the pattern should be clearly and confirmed by both sides

Edge embossing

Steel wheels to steel roller,and controlled by pneumatic

2. AUTOMATIC BAND SAW CUTTER

18d2b7

 Model

Automatic band saw cutting machine

Power

3KW

Raw material

Facial tissue,Core or coreless tissue paper roller without embossing

Raw material



Toilet tissue paper roller

(Length)50-230mm

Diameter),120mm

 Precision

Toilet Tissue Paper Roller

±0.5mm

Control system

PLC

 Double Servo motor drive

 Touch screen operation

 Sharpening System

 Automatic and adjustable

 Round Blade Dia

610mm

 Up&Down Movement

 Hand wheel to adjust

Power

AC380V 50Hz 11.5KW

Air Pressure

0.5Mpa

 Dust Remove Device

 Fixed felts dust box

Production Speed

100—130 Cuts/Min

Packaging

Wooden box

3.Automatic multi-roll Packing Machine(6~12 rolls/bag)

14c3ca

Model

Automatic Toilet Paper Packing Machine

Power

2kw

Packing sizes

L350-600mm*W120-230mm*H60-150mm

Speed

Bags/Min

Packing type

flat roll/ round roll

Control system

PLC control,servo drivetouch screen

flat roll/round roll

up and down sealing/left and right sealing(optional

Air Pressure

0.5Mpa

Power

AC220V,50HZ

Packaging

Wooden box

Wrapping rolls

6~12 rolls in a plastic bag.
